Deslocamento a laser de alta precisão e sensor de distância-Série FLR

Sensor de deslocamento a laser FLR-100-AA Faixa de medição: 150-1000mm Modo de saída: com quantidade de comutador e corrente 4-20mA Precisão de linearidade: Padrão: ± 0,6% F.S. Resolução: 50um a 150 mm; 2mm a 1000 mm Tamanho do ponto: φ3mm a 1000mm Tempo de resposta: 2ms/16ms/40ms podem ser definidos

Laser Displacement Sensor Measuring range: 150-1000mm Output mode: with switching and current 4-20mA Linearity accuracy: ±0.3% F.S. (150-450mm); ±0.6% F.S. (450-1000mm) Resolution: 50um at 150mm; 2mm at 1000mm Spot size: Φ3mm at 1000mm Response time: 2ms/16ms/40ms settable

Sensor de distância de deslocamento do sensor a laser Analog4-20mA de 0,01 mm 80-500 mm Medição e controle integrados do sensor de deslocamento a laser com display digital Faixa de medição de 30-1000 mm com uma variedade de faixas para escolher Configuração conveniente do painel de operação Display digital OLED Com comunicação analógica e RS485 (suporte ao protocolo ModBus) comunicação com múltiplas saídas Precisão linear de até +0,1% F.S. Resolução até 5um

Displacement Distance Sensor Integrated measurement and control of digital display laser displacement sensor Measuring range of 30-1000mm with a variety of ranges to choose from Convenient operation panel configuration OLED digital display With analog and RS485 communication (support ModBus protocol) communication multiple outputs Linear accuracy up to +0.1% F.S. Resolution up to 5um

FLR-10-RS485 -M Laser Displacement Sensor Integrated measurement and control of digital display laser displacement sensor Measuring range of 30-1000mm with a variety of ranges to choose from Convenient operation panel configuration OLED digital display With analog and RS485 communication (support ModBus protocol) communication multiple outputs Linearity accuracy up to ± 0.1% F.S. Resolution up to 5um

FLR-10-RS485 Laser Displacement Sensor Measuring range: 30-100mm Output mode: with switch quantity and RS485 communication (support ModBus protocol) Linearity accuracy: standard type: ±0.3% F.S. (30-100mm); high precision type: ±0.1% F.S. (30-100mm) Repeatability: 10um at 30mm; 0.1mm at 100mm Resolution: 5um at 30mm; 50u m at 100mm Spot size: 1*3mm at 100mm Response time: 2ms / 16ms / 40ms can be set up Ambient light resistance: incandescent light ≥ 3,000lux Operation panel: OLED digital display Temperature drift: ±0.02%F.S./°C

FLR-10-AA 30-100mm Analog4-20mA Laser Displacement Sensor Integrated measurement and control of digital display laser displacement sensor Measuring range of 30-1000mm with a variety of ranges to choose from Convenient operation panel configuration OLED digital display With analog and RS485 communication (support ModBus protocol) communication multiple outputs Linear accuracy up to +0.1% F.S. Resolution up to 5um

FLR-10-AA-M Laser Displacement Distance Sensor Analog 4-20mA Integrated measurement and control of digital display laser displacement sensor Measuring range of 30-1000mm with a variety of ranges to choose from Convenient operation panel configuration OLED digital display With analog and RS485 communication (support ModBus protocol) communication multiple outputs Linear accuracy up to +0.1% F.S. Resolution up to 5um
